3 Compartment Sink Grease Trap Size

The result is the recommended flow rate in gpm of the grease trap.

3 compartment sink grease trap size.

Grease trap with threaded connections prevents greasy substances from entering plumbing systems septic fields and wastewater treatment facilities where they cannot be processed properly and could harm the environment. Determine the flow rate for each sink to be serviced by the grease trap using the same calculations as a single sink. Each dishwasher will require a seperate grease trap. This grease trap is different from traditional metal grease traps since it is made of a durable seamless polyethylene material that will not.

Temperatures must be less than 120 degrees prior to entering grease trap. Each fixture trap shall have a liquid seal of not less than 2 inches 51 mm and not more than 4 inches 102 mm except where a deeper seal is found necessary by the authority having jurisdiction. Gpm x 0 75 gpm actual drainage load for sinks. If draining multiple fixtures into one grease trap.

One trap serving a three compartment sink shall have the trap centrally located. No food waste disposal unit shall be installed with any set of restaurant sinks served by a single trap. All grease bearing waste streams should be routed through an appropriate grease traps grease interceptor including. Grease ducts shall be sized between 500 2500 fpm.

The ashland polytrap 4825 50 lb. Adjust for displacement displacement takes into consideration the actual usable capacity of your sink. Dishwashers can be connected to a grease trap only if allowed by local code. Floor sinks that receive only ice machine and cooler condensate are not counted.

Three compartment sinks pot pan sinks soup kettles handwashing sinks dishwashers mop sinks and floor drains. Traps shall be set true with respect to their liquid seals and where necessary they shall be protected from freezing. 3 compartment sink 9 2 compartment sink use floor sink criteria based upon drain size or number of sinks whichever is larger each compartment is 3 dfus. Add together 100 of the largest flow rate 50 of the second largest and 25 of all others.

Grease trap sizing hydro mechanical 2 or 3 compartment sink cubic capacity width x length x depth in inches volume in gallons cubic capacity 231 1 us gallon 231 cubic inches volume remember. Use a separate trap. Hydro mechanical interceptors are measured by flow gpm grease interceptor sizing gravity. Use floor sink criteria based upon drain.

Add together 100 of the largest flow rate 50 of the second largest and 25 of all others.
